The Treehouse

REMEDIATION PROJECT

JULY 2019

7/29/2019

7/30/2019

7/31/2019

8/1/2019

A R C H I V E

Site:  329 Shore Rd Fayette ME   04349.  See site map below.  We are lot 11 on that map.  The driveway goes along the border with lot 12.  The house is about halfway between road and water.  There is a rock ledge cliff in from of the house (toward the pond).  The shoreline buffer zone is approximately 40 feet beyond the deck.


Orientation: The wall between posts 1 & 2 faces east


PRE-ADDITION PHOTOS (BEFORE SUMMER 2017)


Images: I labeled the images by the post numbers, so wall_3_2 is the wall between posts 3 & 2.


Site map

interior pano

Center post (this is the central support structure - think umbrella)

septic line

architectural plans

PRE-ADDITION PHOTOS

wall 1_8

wall 3_2

wall 8_7

walls 6_5_4

POST-ADDITION PHOTOS

side1-2

side2-3

side5-6

side6-7

side7-8

addition elevation

grade drop-off beyond addition

southern boundary is approx. 20 ft to the right


Structural notes:

  • 1. The bottom level is 400 sq. ft, and the (post addition) top level is c.1050 sq. ft.
  • 2. The plumbing waste line goes out from wall 1_2, closer to post 1. In the septic line image, the septic storage tank os between the receptacle on the right and the stick in the ground.   Waste is then pumped to a field that is about 70-80 feet east of the house.
